Dimensions
Item Specification
Internal Size 4.0 m (Width) ? 4.0 m (Length)
Plate Thickness 10 cm (Heavy Duty)
Category Heavy Duty
3. Structural Components
Main Body
Fabricated from rectangular hollow sections
Tube Size: 15 ? 10 cm
Upper Beam
H-Beam
Size: 10 ? 10 cm
C-Channel
Length: 2.44 meters
Type: Heavy Duty
Side Frames
U-Beams (Heavy Duty Grade)
Cutting Knife Edge
Thickness: 5 mm
Height: 25 cm
Reinforced for soil penetration and stability
4. Adjustable Hydraulic / Mechanical Jacks
Item Specification
Type Heavy Duty Adjustable Jack
Closed Length 1.3 m
Open Length 2.0 m
Male Tube 8 ? 8 ? 8 mm
Female Tube 10 ? 10 ? 8 mm
5. Application
Deep trench excavation
Pipeline installation
Sewer & water network projects
Cable trench works
Infrastructure projects
6. Material & Fabrication
High-grade structural steel
Heavy-duty welding
Designed for high soil pressure resistance
Suitable for medium to hard soil conditions
7. Optional Additions (If Available)
Extra extension panels
Custom jack sizes
Transportation service
Installation supervision
