A pet granulator line perform secondary or fine size reduction and are typically placed after shredding and initial washing steps.Its primary purpose is to produce uniform PET flakes that meet quality requirements for washing,drying,and final applications.
PET Granulator Line Output
The pet granulator’s capacity range from 300 kg/h to 7000 kg/h,this granulator line is designed to meet the rigorous demands of industrial-scale recycling plants worldwide.
PET Granulator Line Material
This plastic granulating line’s frame is made anti-corrosion and wear-resistant material and the parts contact with material is made of 304 stainless steel.
Features of PET Granulator Line
Our pet plastic recycling granulator machine’s key features include as follow:
Cutting & Size Reduction
• Above pet granulating machines employ a fast-spinning rotor mounted with multiple angled knives that cut material against stationary bed knives with a precise scissor-like action.
• A screen with specific hole sizes is located beneath the cutting chamber,ensuring that only material reduced to the desired flake size can exit.Typical PET flake sizes range from 8mm to 14mm.
• The defining feature of a pet granulating machine is its ability to produce consistently sized and shaped flakes,which is crucial for the quality of the final rPET.
Wet Granulation System
• A wet granulator uses an added waterline to continuously spray water into the cutting chamber.This partially cleans the PET flakes and acts as a lubricant,lowering friction and heat within the cutting chamber.
• By adding water to the cutting chamber,the frequency of knife sharpening can be decreased by two to three times.
Pelletizing / Granulation Process
• A pet plastic granulator converts pet raw materials into high-purity,low-water-content recycled particles through melt extrusion,water-cooled stranding,cutting,and granulation,suitable for downstream fields such as chemical fiber,packaging,and sheets.
• The pet granulator machine supports flexible die head options for pelletizing,such as water ring cutting,underwater cutting,and hot face cutting.
Filtration & Drying
• The pet pellets maker is equipped with a multi-stage filtration water circulation system to reduce impurity pollution; integrated centrifugal dehydration and hot air drying modules reduce the moisture content of particles (usually below 0.02%),meeting food-grade recycling requirements.
• The pet reprocessing equipment includes a stable drying system,strong vacuum degassing system,efficient filtration system,strand cutting system,and viscosity equipment,all ensuring high-quality final PET pellets.
Screw & Feeding System
• The pet granulator line system allows free assembling of the screw component based on raw material type,and a high-efficiency force feeder ensures stable high-capacity material feeding with low power consumption.The main screw also has vacuum exhaustion.
Automation & Control
• Intelligent control via PLC or IoT technology enables real-time monitoring of temperature,water pressure,cutting speed,and other parameters.
• PET strips flow automatically in the water trough and are granulated without manual pulling,even if strips break off during the process.
• Pastic flakes recycling machines for wet operation combine exceptionally high throughput rates and low fines production with a wear-resistant,low-maintenance design.
Energy Efficiency
• With forced feeding,certain plastic granulating machines can increase throughput by up to 50% and reduce energy consumption by up to 30%.
Output Applications
• The resulting uniform,high-quality granules are suitable for various industrial applications such as fiber production,injection molding,and more.
